Instantor Foil-PRO™ The Foil Faced XPS Panel system is a quick, easy to install panel intended for use in overlay applications where minimising the overall build-up height is required. Can be installed over solid and timber substrates, providing the floor is solid and level.
Consisting of a high-density 18mm aluminium foil faced XPS (400 kPa) panel incorporating 12mm pipework laid at 150mm centres, this system can be used with low temperature heating systems as the foil face helps maximise efficiency by spreading heat across the foil, and through the finished floor coverings.
Suitable for use with carpets and tiles where a structural/decoupling layer (such as Murexin 4mm Unitop bonded to the foil using Murexin MS K-509 Contact Adhesive) is installed over the foil faced XPS panels. Timber flooring >15mm thick can be installed directly over the foil faced XPS panels.
Warranty
Pex-Al-Pex: 50 Years, Pert-Evoh-Pert: 50 Years, Manifold: 5 Years, Mixing Kit: 5 Years, Pump: 5 Years, Whisper Controls: 5 Years
Key Features
Quick & easy to install
Suitable for use with low temperature heating systems
Lightweight & easy to cut/trim
Low Profile Floor Build-Up
Can be laid over Solid or Timber Floors
400kPa Compressive Strength allows for increased structural integrity
Omega pipe channels ensuring pipe stays in place when under tension
Easy management of connection pipes with flow and return pathways integrated into the panel
Available Options
|
Pipe Types Available |
12mm 5-Layer PE-RT/EVOH |
|
Typical Pipe Spacings (mm) |
150mm |
Pipework Layout Suitability
Floor Covering Suitability
Seek advice from floor covering manufacturer regarding installation methods prior to installation
Heat Output
Watts per m² at 150mm Pipe Centres
| Pipe Spacing | 150mm | ||||
| Design Room Temperature | 20°C | ||||
| UFH Pipe Circuit ΔT | 5°C | ||||
| Floor Covering Resistance (TOG) |
Flow Temperature (°C) | ||||
| 30 | 35 | 40 | 45 | 50 | |
| 0.00 | 32 | 54 | 75 | 97 | 118 |
| 0.50 | – | 35 | 49 | 63 | 77 |
| 1.00 | – | – | 30 | 38 | 47 |
| 1.50 | – | – | – | – | 33 |
| 2.00 | – | – | – | – | – |
| 2.50 | – | – | – | – | – |
| Pipe Spacing | 150mm | ||||
| Design Room Temperature | 20°C | ||||
| UFH Pipe Circuit ΔT | 7°C | ||||
| Floor Covering Resistance (TOG) |
Flow Temperature (°C) | ||||
| 30 | 35 | 40 | 45 | 50 | |
| 0.00 | – | 49 | 71 | 92 | 114 |
| 0.50 | – | 32 | 46 | 60 | 74 |
| 1.00 | – | – | – | 37 | 45 |
| 1.50 | – | – | – | – | 32 |
| 2.00 | – | – | – | – | – |
| 2.50 | – | – | – | – | – |
