ACR Press Fittings
The Safer, Faster Way to join air conditioning and refrigeration pipework.
Instantor’s new R-Press system is a game-changer for ACR installers. Designed for high-pressure applications up to 48 bar, including refrigeration, air conditioning, heat pumps (refrigeration side), VRF, and VRV systems – R-Press fittings deliver clean, reliable joints without the hassle of flame-based methods.
Because it’s flame-free, there’s no need for hot work permits, fire watches, or lengthy risk assessments. That means quicker installs, less downtime, and safer working conditions, especially in tight or sensitive spaces.
Instantor R-Press fittings use a precision-engineered 3-point press design for strong, permanent joints you can count on. It’s a mechanical joint, so there’s no need for nitrogen purging, which keeps your systems
cleaner and your installs simpler.
Built with the quality and reliability you expect from Instantor, R-Press fittings help reduce callbacks and keep projects moving efficiently. They’re also designed with installers in mind, no fuss, no flame, just dependable performance.
The Instantor R-Press system is fully compatible with a wide range of press tools and jaws in the industry.
Whether you’re using your own tool or jaws from otherbrands, the Instantor R-Press fittings integrate seamlessly to ensure reliable and efficient performance.
Tools with a 19kN force rating are approved for use with press fittings and tubing up to 1 1/8″, while jaw and tool compatibility spans sizes from 1/4″ to 1 1/8″.
Please note that while most major 19kN tools are supported, a few select models may not be compatible.
HIGH-PERFORMANCE PRESS FITTINGS
rated up to 48 bar for demanding applications including refrigeration, air conditioning, heat pumps (refrigeration side), VRF, and VRV systems
CONSISTENT, LEAK-FREE JOINTS
Installed using a press tool for consistent, permanent joints every time
DISTINCTIVE PINK MARKING
For easy on-shelf and on-site product identification
COMPREHENSIVE SIZE RANGE AVAILABLE
¼ ”, 3/8”, ½ ”, 5/8”, ¾ ”, 7/8”, 11/8
FAST, CLEAN, AND FLAME-FREE INSTALLATION
Safer and more efficient alternative to brazing – no hot works required
TOOL COMPATIBILITY
Fully compatible with Instantor Press Tools and most commonly used press tools on the market
VERSATILE REFRIGERANT COMPATIBILITY
Suitable for a wide range of commonly used refrigerants
15-YEAR WARRANTY
With Instantor approved installer training – adds confidence at the point of sale
